Part #: B305SM-XIW-014V

LED Bulb, 5-SMD, Miniature Bayonet T3-1/4 (Ba9s), Hi-Lumen

Direct Incandescent Replacement Up to 90% Energy Savings

14Vac/dc, 3000K Warm White

Replaces Incandescent/LED:1815, 1889, 1891

Features
  • 3 Year LEDtronics Warranty
  • Suitable for enclosed Ba9s fixtures where temperatures will not commonly exceed the recommended operating range.
  • Low power consumption, Ultra bright intensity
  • Energy savings up to 90%
  • Lumen maintenance over 70% @ 15,000 hours
  • Solid-state: High-shock & vibration resistant
  • No UV, no RF interference, minimal heat (IR)
  • Sunlight-visible LEDs, even lighting
  • 40+ Years LEDtronics Design & Manufacturing



Choose Options:

Voltage Options
Color/Temp Options

Spec Sheets




Applications

  • Replaces bayonet-based lamps operating at 14Vac or 14Vdc within its dimensional constraints
  • Indicator lights for instrumentation
  • Panel mount pilot lights
  • Accent lighting
  • Back lighting
  • Signage
  • Not advisable to have bulb enclosed in lenses where temperatures could exceed operating range

Specifications

 Voltage12 VAC12 VDC14 VAC14 VDC
 Web DescriptionLED Lamp,Miniature Bayonet T3-1/4 (Ba9s),1.12"Lx0.44"D,Warm White,14Vac|14Vdc
 Description***12/14Vdc,W.White,Ba9s Min.Bay,SMD
 Base TypeMiniature Bayonet T3-1/4 (Ba9s)
 Dimensions1.12"Lx0.44"D
 ColorWarm White
 Color Temp3000K
 Polarity (Center Contact)AC BipolarDC AC BipolarDC
 Voltage (V)14Vac/dc
 Power (Watts)0.9 W 0.7 W 1.6 W1.3 W
 Current (Amps)0.082 A 0.0557 A 0.119 A 0.0941 A
 Operating Temp~-40°C to ~+100°C, Dry locations
 Intensity (Candela)0.016 cd 8.243 cd 1.8501 cd 11.7195 cd
 Lumens70.27 lm 66.41 lm 105.6 lm 105.4 lm (lumen)
 SCP (Spherical Candela)5.592 5.285 8.403 8.384 mscp
 Viewing Angle160°
Electrical-Optical Characteristics (Ta = 25°C)

Options

  • Other Colors
  • Other Voltages

Caution

  • Do not install where illuminating lamp will exceed operating temperatures.

Prop. 65 Warning
WARNING: This product can expose you to chemicals including Di(2-ethylhexl)pthalate (DEHP), which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
