Part #: PT503B-0PB-024V-T18  (24Vdc,BLU,8mm Mtg.Dia,0.110" Tab,IP66)

Panel Mount Indicator, Super Blue, Bolt-on, 8mm, 24Vdc, Male terminal tabs (3/16")

Black Low-profile bezel, Flush mount, Fits 0.316" Mounting diameter panel hole

Black threaded metal body, IP66 rated

LED/Incandescent Cross Reference Tool

Features
  • 3 Year LEDtronics Warranty
  • 100,000 hour long service life, low maintenance
  • IP66 rated enclosure has protected resistance to strong jets of water
  • 8 mm mounting hole diameter for panels 0.5 to 8.0 mm thick
  • Male tab terminals: 0.110-in.
  • Threaded black nylon housing with black bezel
  • Available as red, yellow, green, blue, and white illumination colors
  • 40+ Years LEDtronics Design & Manufacturing



Choose Options:

Voltage Options
Color Options

Spec Sheets






Applications

  • Industrial Panels
  • Pilot Lights for Machines & Instruments
  • Automotive Indicators

Specifications

 Voltage24 VAC24 VDC
 Web DescriptionLED Lamp, Mini. Bayonet T3-1/4 (Ba9s), 1.12"Lx0.44"D, Pure White, 24Vac|24Vdc
 Description24Vac/dc,P.White,Ba9s Min.Bay,SMD
 Base TypeMini. Bayonet T3-1/4 (Ba9s)
 Dimensions1.12"Lx0.44"D
 ColorPure White
 Color Temp5000K
 Polarity (Center Contact)AC BipolarDC
 Voltage (V)24V (ac/dc)24V (ac/dc)
 Power (Watts)1.2 W1.2 W
 Current (Amps)0.052 0.049 A
 Operating Temp~-40°C to ~+100°C, Dry locations
 Intensity (Candela)2.4 cd 4.6 cd
 Lumens55 lm 63 lm (lumen)
 SCP (Spherical Candela)4.35 4.98 mscp
 Viewing Angle160°
Electrical-Optical Characteristics (Ta = 25°C)

Possible Options

  • Other voltages
  • Other terminations: Wire leads, Screw terminals
