Home > Products > RPLH16-02-02-02
Part #: RPLH16-02-02-02
(130Vdc/120Vac,Sp.Amber,16mm Mtg.Dia)
Panel Mount LED Pilot Light, Relampable, 130Vdc/120Vac, 1-LED, 16mm (5/8") Mtg.Dia.Single LED, Super Orange, Rear MountComparable to UL 508 & NEMA 3, 4, 4X, 5, 6, 12
Single LED, Super Orange, Rear MountComparable to UL 508 & NEMA 3, 4, 4X, 5, 6, 12
Comparable to UL 508 & NEMA 3, 4, 4X, 5, 6, 12
| Replaces Incandescent/LED: | Industrial Rear Mount Pilot Lights in 16mm (5/8")Mtg.Dia. |
| LED/Incandescent Cross Reference Tool |
Features
- 3 Year LEDtronics Warranty
- Long Life. Energy Savings. Shock/Vibration Resistant
- Rear Mount in 16mm (5/8") Mounting Hole
- Maximum panel thickness: 0.25" [6.35mm]
- Ultra-Bright 1-LED Relampable Bulb
- Available in higher intensity 4 or 7 LED versions
- Choice of other standard LED Colors & Input Voltages
- Available Voltages with No Glow below 50V
- Available in 22mm, 30mm mounting diameters
- UL Recognized. RoHS Listed
- Volume Discount Price available. Contact Sales
Price: $35.06 each | Min Qty: 10
Choose Options:
Voltage OptionsColor Options
Specifications
| Web Description | LED Bulb,Intermediate,SMD LED, Double Contact DC Bayonet Ba15d, 1.84"Lx0.87"D, Super Blue, 24Vdc |
|---|---|
| Description | 24V-BP,Blue,SMD LED,Ba15d Base |
| Base Type | Double Contact DC Bayonet Ba15d |
| Dimensions | 1.84"Lx0.87"D |
| Color | Super Blue |
| Wavelength (nm) | 462nm |
| Voltage (V) | 24Vdc |
| Power (Watts) | 1.08 W |
| Current (Amps) | 0.045 A |
| Operating Temp | ~-30°C to ~+50°C |
| Intensity (Candela) | 0.920 cd |
| Lumens | |
| SCP (Spherical Candela) | |
| Viewing Angle | |
| Electrical-Optical Characteristics (Ta = 25°C) | |
Caution
- (Concerning single color panel holders only, not bicolor holders): RPLH holders and indicators do not have polarity markings since they all use bipolar LED bulbs which are not sensitive to polarity
For qualified applications and large quantity orders
PilotLED Assembly Part Number Example:
02 = (1-LED, 5mm); 06 = (4-LED, 5mm); 03 = (7-LED, 3mm)
* Volts = Full voltage. Customer defines incoming voltage, lamp in holder is made to that voltage.
This holder contains no current limiting resistor. (Example RPLH16-24-01-02 [24 Volt incoming source])
** = 48 & 130VDC use an internal series resistor to drop the voltage across the LED bulb to 28 Volts.
